Team Details
Lund Formula Student
| University | Lund University
SE Lund U short 169 |
 |
|---|---|---|
| Location | Lund, Sweden | |
| Homepage | https://www.lundformulastudent.se | |
| Social Media |

|
|
| CV Team | Lund Formula Student | |
| DV Team | Lund Formula Student | |
| Short Link | tid.fsg.one/1049 | |
Team Description
Lund Formula Student was previously known as LU Racing and has been building racing cars since 2006.
Event Profile
Past Events
2026
Info
At Lund Formula Student, coffee, carbon fiber and crazy ideas come together to build a real race car from scratch. We're a Swedish student-driven team from the south of Sweden, representing Lund University. This year revolves around switching to hub motors from our previous RWD concept, also focusing on autonomous functionality.
Engineering Design Priorities:
Reliability - Working car
Manufacturability - Good
Performance - Fast car
Autonomous - Lighter car
Controls - Handling car
Innovation - Creative car
Car Specifications
General
| Frame Construction | CFRP monocoque |
|---|---|
| Material | Aluminium honeycomb core with T700 & T300 fibres |
| Overall Length (mm) | 2855 |
| Overall Width (mm) | 1608 |
| Overall Height (mm) | 1048 |
| Wheelbase (mm) | 1535 |
| Track Front (mm) | 1250 |
| Track Rear (mm) | 1250 |
| Suspension | Double A-Arm, pushrod w/ Öhlins TTX25 MkII 4-way adjustable corner dampers, 1 ARB/axle |
| Tyres | Hoosier 16x7.5-10” R20 |
| Wheels | OZ Carbon fiber-aluminium center locking |
| Brake System | Dual circuit w/ adjustable front-rear bias, drilled, floating discs. Fr 180mm, Rr 180mm |
Powertrain
| Number of Motors | 4 |
|---|---|
| Motor Location | FR, FL, RR, RL |
| Max Motor Power | 35kw (all) |
| Motor Type | DTI F-MOT (all) |
| Max Motor RPM | 20.000 rpm (all) |
| Motor Controller | DTI F-SIC |
| Max System Voltage (V) | 616V |
| Electrode Materials | NMC532 - graphite |
| Accumulator Capacity | 7.07kWh |
Driverless System
| Processing Units | SAMC21G18A, STM32H723GZ, Intel 12700K with 32GB RAM |
|---|---|
| Processing Units FLOPS | 1300 |
| Processing Units Power (W) | 60 |
| Cameras | None |
| Radar Sensors | None |
| LiDAR Sensors | 1x Hesai 40P, 360 deg horizontal FOV, 40 channels |
FS past achievements due to World Ranking Data Base
| Date | Event | Teams | Rank | BP | CM | ED | SP | DV SP | AC | DV AC | AX | EN | EF | Pe | Total |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2025.08 | 53 |
18. |
34. |
11. |
26. |
15. |
- |
29. |
- |
19. |
15. |
13. |
0.00 |
388.15 |
|
| 2025.07 | 44 |
15. |
9. |
9. |
11. |
15. |
- |
- |
- |
14. |
- |
- |
-20.00 |
281.49 |
|
| 2024.08 | 47 |
9. |
13. |
13. |
26. |
18. |
- |
19. |
- |
10. |
9. |
11. |
0.00 |
494.20 |
|
| 2024.07 | 31 |
14. |
3. |
25. |
16. |
11. |
- |
11. |
- |
10. |
- |
- |
-10.00 |
243.98 |
|
| 2023.08 | 31 |
10. |
9. |
22. |
23. |
13. |
- |
14. |
- |
10. |
8. |
8. |
0.00 |
474.79 |
|
| 2023.07 | 33 |
9. |
11. |
22. |
24. |
- |
- |
- |
- |
- |
3. |
3. |
0.00 |
321.45 |
|
| 2022.08 | 25 |
18. |
23. |
10. |
13. |
- |
- |
19. |
- |
13. |
- |
- |
-50.00 |
186.30 |
|
| x 7 | |||||||||||||||
