Team Details
Salento Racing Team
| University | Università del Salento
IT Lecce U short 463 |
|---|---|
| Location | Lecce, Italy |
| Homepage | https://salentoracingteam.it/ |
| Social Media |
|
| EV Team | Salento Racing Team |
| Short Link | tid.fsg.one/198 |
Event Profile
Past Events
2011
Info
Salento Racing Team(SRT)represents much more than a simple group of students but an innovation lab in which skills and attitudes are emphasized. Thus, Engineering turns out magnified by matched efforts of different branches of knowing. In fact, the desire of reaching higher and higher results and to face newer and newer challenges are basic characteristics of SRT. In this context, SRT11 embodies an effective turning point in prototypes development, providing outstanding features such as a very stiff carbon fiber monocoque, important composite items (steering wheel, suspensions A-arms, fuel tank), gear & clutch pneumatic actuation, an optimized engine with customized head piston shapes and camshafts, launch control and much more. Eventually, SRT proudly represents a convergence point of some of the most innovative and competitive companies of our land, Salento. Hence, great expectation of an entire people encourages our steps to the success and we are keen on satisfying them.
Car Specifications
General
| Frame Construction | Carbon Fiber Monocoque |
|---|---|
| Material | Sandwich made by CC201 Saati HS carbon fiber, Airex C70.55 PVC as core material |
| Overall Length (mm) | 2742 |
| Overall Width (mm) | 1444 |
| Overall Height (mm) | 1077 |
| Wheelbase (mm) | 1620 |
| Track Front (mm) | 1240 |
| Track Rear (mm) | 1200 |
| Weight Front (kg) | 127 |
| Weight Rear (kg) | 158 |
| Suspension | Double unequal length A-Arm. Front Push/Rear Pull rod actuated horizontally oriented spring&damper |
| Tyres | 20.5x7.0-13 HOOSIER R25B/ 20.5x7.0-13 HOOSIER R25B |
| Wheels | 7.0x12, 22mm pos. offset, Al-Mg Rim/7.0x12, 22mm pos. offset, Al-Mg Rim |
| Drive Type | Chain Transmission |
| Differential | Limited slip differential |
| Cooling | Single260x460alum Rad with thermostatic controlled electric fans |
| Brake System | 4- Floating Disc System, 218mm diameter rotors, adjustable brake balance, APracing calipers |
| Electronics | Multifunctional Steering Wheel, Electropneumatic shifting system,selfdesigned Telemetry System |
Powertrain
| Engine | Modified Honda CBR600F |
|---|---|
| Bore (mm) | 67.0 |
| Stroke (mm) | 42.5 |
| Cylinders | 4 |
| Displacement (ccm) | 599 |
| Compression Ratio | 12,8:1 |
| Fuel System | Athena get data Walbro system with indirect sequential injection |
| Fuel | 98 octane unleaded gasoline |
| Max Power (kW) | 10500 |
| Max Torque (Nm) | 7000 |
FS past achievements due to World Ranking Data Base
| Date | Event | Teams | Rank | BP | CM | ED | SP | DV SP | AC | DV AC | AX | EN | EF | Pe | Total |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2023.07 | 22 |
15. |
20. |
12. |
12. |
- |
- |
- |
- |
- |
- |
- |
0.00 |
162.11 |
|
| 2016.07 | 38 |
15. |
26. |
3. |
4. |
18. |
- |
9. |
- |
17. |
14. |
- |
0.00 |
406.11 |
|
| 2015.09 | 43 |
28. |
34. |
4. |
19. |
12. |
- |
17. |
- |
30. |
33. |
- |
0.00 |
322.49 |
|
| 2015.08 | 28 |
17. |
15. |
20. |
11. |
18. |
- |
20. |
- |
13. |
11. |
- |
0.00 |
264.27 |
|
| 2012.09 | 16 |
11. |
7. |
2. |
5. |
11. |
- |
9. |
- |
10. |
- |
- |
0.00 |
336.76 |
|
| 2012.07 | 97 |
47. |
49. |
13. |
32. |
- |
- |
- |
- |
- |
38. |
- |
-4.00 |
212.20 |
|
| 2011.09 | 49 |
26. |
19. |
4. |
16. |
36. |
- |
33. |
- |
28. |
34. |
- |
0.00 |
369.00 |
|
| 2011.08 | 74 |
70. |
48. |
66. |
71. |
- |
- |
- |
- |
- |
- |
- |
0.00 |
109.66 |
|
| 2009.09 | 36 |
26. |
25. |
1. |
26. |
27. |
- |
27. |
- |
26. |
17. |
- |
0.00 |
286.78 |
|
| 2008.09 | 31 |
28. |
30. |
18. |
27. |
23. |
- |
25. |
- |
25. |
- |
- |
0.00 |
172.60 |
|
| 2006.09 | 17 |
18. |
16. |
17. |
17. |
13. |
- |
15. |
- |
16. |
- |
- |
0.00 |
98.90 |
|
| x 11 | |||||||||||||||
